Server Type / Form Factor |
- Type:Enterprise Rack Server
- Form Factor: 2U Rack
- Socket: Dual-socket (supports 1 or 2 Intel Xeon 6 processors)
|
- Type: Enterprise Rack Server
- Form Factor: 2U Rack
- Socket: Dual-socket (2 x Intel Xeon 6 Processors)
|
|
Processor (CPU) |
- Processor Family: Intel Xeon 6 Scalable Processors
- Max Sockets: 2
- Cores per Socket: Up to 144 cores
- Max Speed: Up to 3.9 GHz (varies by processor model)
- Memory Channels: 8 channels per processor
|
- Processor Family: Intel Xeon 6 (E-core and P-core series)
- Max Sockets: 2
- Max Cores per Socket: Up to 144 E-cores or 86 P-cores
- Max TDP: Up to 500 W per processor
- Max L3 Cache: Up to 480 MB per processor (varies by SKU)
|
|
Memory (RAM) |
- Memory Type: HPE DDR5 Smart Memory (RDIMM)
- DIMM Slots: 32 DIMM slots (16 per processor, 2 DIMMs per channel)
- Maximum Capacity: Up to 8 TB (with 256 GB modules)
- Maximum Speed: Up to 6400 MT/s at 1DPC (depends on CPU and DIMM population)
- Memory Protection: Advanced ECC, online spare, mirroring, combined channel (lockstep)
|
- Memory Type: DDR5 RDIMM (registered ECC only)
- DIMM Slots: 32 DIMM slots (16 per processor)
- Maximum Capacity: Up to 8 TB
- Speed: Up to 6400 MT/s
- Protection: ECC with advanced RAS features
|
|
Storage |
- Front Drive Options: Up to 36 EDSFF E3.S NVMe drives
- Additional Drive Options: Up to 24 SFF bays (SAS/SATA/NVMe)
- LFF Bays: Up to 12 LFF bays (SAS/SATA)
- Max Internal Storage: 550.8 TB using 36 x 15.3 TB EDSFF NVMe
- Alternative Capacity: 480 TB using LFF SAS/SATA SSDs in 12+4+4 configuration
- RAID Support: HPE Smart Array controllers (RAID 0, 1, 5, 6, 10, 50, 60 – depending on controller)
|
- Drive Bay Options: Up to 16 x EDSFF E3.S NVMe
- Configuration Option: 24 x 2.5-inch SAS/SATA/NVMe
- Configuration Option: 12 x 3.5-inch SAS/SATA
- Hybrid Configurations: Supported
- Supported Drives: SAS, SATA, NVMe SSD/HDD (2.5-inch, 3.5-inch, EDSFF E3.S)
- RAID Support: PERC H365i/H965i/H975i controllers (RAID 0, 1, 5, 6, 10, 50, 60)
|
|
Expansion / Connectivity |
- PCIe Slots: Multiple PCIe 5.0 slots (including up to four PCIe x16 full-height, full-length slots)
- OCP Slots: Up to two front OCP 3.0 slots for high-speed NICs or accelerators
- Networking: OCP 3.0 FlexibleLOM (choices of 1/10/25/100GbE)
- GPU Support: GPU-accelerated configurations and GPU-performance kits available for AI and HPC workloads
|
- PCIe Slots: Up to 8 PCIe Gen5 slots (mix of x8/x16 full-height/full-length)
- OCP Slots: Up to 2 OCP NIC 3.0 (1/10/25/100/400 GbE)
- Networking: 1 GbE BMC + PCIe add-in cards (InfiniBand, 400 GbE, FC)
- GPU / Accelerator Support: Multiple GPU options with optional Direct Liquid Cooling
|
|
Redundancy & Reliability |
- Power: Redundant hot-plug power supplies (various wattages and efficiency grades)
- Cooling: Redundant hot-plug fans; optional direct-liquid cooling-compatible designs
- Storage: Hot-swap drive bays and RAID-based redundancy options
- Availability Features: HPE-engineered reliability, service-level-ready architectures
|
- Power: Redundant hot-plug PSUs (800W–3200W Platinum/Titanium)
- Cooling: Redundant hot-swap fans; optional Direct Liquid Cooling (DLC)
- Reliability: Hot-swap components, OCP DC-MHS modular design
|
|
Operating System Support |
- Microsoft Windows Server
- Red Hat Enterprise Linux (RHEL)
- SUSE Linux Enterprise Server (SLES)
- VMware ESXi
- Canonical Ubuntu
- Oracle Linux
|
- Microsoft Windows Server with Hyper-V
- Red Hat Enterprise Linux (RHEL)
- Canonical Ubuntu Server LTS
- VMware ESXi
- SUSE Linux Enterprise Server (SLES)
|
|
Security Features |
- Silicon Root of Trust
- Secure Boot, Secure Start
- Intel TME (Total Memory Encryption)
- Firmware and Runtime Integrity Monitoring
- UEFI-managed encryption and privilege-separation controls
- Industry-standard compliance (ACPI 6.5, PCIe 5.0, PXE, Wake-on-LAN)
|
- Dell SafeBIOS Secure Core
- System Lockdown and Cryptographic Erase
- Firmware Update Verification and TPM 2.0
- Secure Boot and Multi-Factor Authentication
|
|
Management & Monitoring |
- HPE iLO 7: Embedded management for remote console, BIOS setting, firmware updates, and alerts
- HPE Compute Ops Management: AI-driven operations dashboard and lifecycle automation
- APIs: RESTful / Redfish-based interfaces for integration with third-party tools
|
- iDRAC10 Enterprise: Embedded remote management
- Dell OpenManage Enterprise: AI-driven centralized management
- APIs: Redfish APIs and RESTful interfaces for automation
|
|
Warranty & Support |
- Standard Warranty: 3 Years Parts, 3 Years Labor, 3 Years Onsite (varies by region and contract)
- Optional Support: HPE Pointnext, Foundation Care, Proactive Care, and custom SLAs
|
- Standard Warranty: 3 Years ProSupport (parts, labor, onsite)
- Optional Support: ProSupport Plus, ProSupport Enterprise, extended terms, AI-driven proactive analytics
|
